Product Advantage :
The automatic fecal scraping system includes scraper, transmission device and automatic control system. The automatic control system controls the manure scraper trolley and transmission device, and the scraper is pulled through the driving device to slide back and forth in the manure ditch of the pig house to scrape the pig manure to the manure collection tank outside the pig house. The times of scraping feces per day can be set randomly according to the fecal yield.
◆ Main engine: 304 stainless steel outer skin assembly, nodular cast iron main engine wheel, Taiwan brand gear reduction motor motor, new inlaid bearing main engine.
◆ Corner wheel: the outer surface is made of 201 stainless steel and the inner surface is made of nodular cast iron.
◆ Control box: integrated microcomputer distribution box, made of precision plastic steel, integrated microcomputer control, with functions of wrong items, missing items, loose rope, end-to-end restoration of board, and over range protection;
◆ Fecal scraping board: flat scraping board, all 304 stainless steel plates；
◆ Steel wire rope: 304 stainless steel, 10mm thick;
◆ Accessories: travel switch travel switch bracket, motor line signal line expansion screw, etc.
