Product Advantage :
◆ Chain type feeding system: each chain is delivered after tensile strength test.
◆ The test strength of 5mm diameter chain is 1600kg, the test strength of 6mm diameter chain is 2200kg, and the test strength of 7mm diameter chain is 3500kg.
◆ Advantages of strength test: 1: avoid damage and fracture of solder joints.
◆ Advantage 2: during the trial run after installation, the chain extension length is reduced.
Chain&Disk | Product Name | Material | Suitable Tube Diameter | Basic parameters | Tensile Test | Packing |
| SQT-AC001 | 36 Chain&Disk | Chain：20MnZ（Galvanized） Plug disc: nylon, d75 hardness | Φ45MM | Plug Disc Spacing∶70mm Plug Disc Diameter∶36mm Chain Diameter∶5mm | 1600KG | 640*470*300mm 100m/carton |
| SQT-AC002 | 40 Chain&Disk | Φ60MM | Plug Disc Spacing∶70mm Plug Disc Diameter∶40mm Chain Diameter∶5mm | 1600KG | ||
| SQT-AC003 | 45 Chain&Disk | Plug Disc Spacing∶70mm Plug Disc Diameter∶45mm Chain Diameter∶5mm | 1600KG | |||
| SQT-AC004 | 45 Chain&Disk （Reinforced） | Plug Disc Spacing∶70mm Plug Disc Diameter∶45mm Chain Diameter∶6mm | 2200KG | |||
| SQT-AC005 | 45 Chain&Disk | Plug Disc Spacing∶90mm Plug Disc Diameter∶45mm Chain Diameter∶5mm | 1600KG | |||
| SQT-AC006 | 75 Chain&Disk （Reinforced） | Φ102MM Φ90MM | Plug Disc Spacing∶92mm Plug Disc Diameter∶45mm Chain Diameter∶7mm | 3500KG |
